3 Hartmann Carding set
EUROPE (Western and Northern)
n.01 carding set, make HARTMAN , ww 1850 mm, 3,5 swift , composed with :
n.01 Hopper feeder with double feeding system
n.01 breast cylinder dia. 720 mm with 4 couples
n.01 cylinder transfer dia 460 mm.
n.01 groups cylinder( first group) dia 1280 mm with 5 couples
n.01 doffer ( first group) dia.1230 mm
n.01 peralta
n.01 scotch feed ww
n.01 groups cylinder( second group) dia 1280 mm with 5 couples
n.01 doffer ( second group) dia.1230 mm
n.01 groups cylinder( third group) dia 1280mm with 5 couples
n.01 doffer ( third group) dia.1230mm
n.01 condenser with 168 goo ends , single tape of 10.6 mm.
n.01 carding set, make HARTMAN , ww 1850 mm, 3,5 swift , composed with :
n.01 Hopper feeder with double feeding system
n.01 breast cylinder dia. 720 mm with 4 couples
n.01 cylinder transfer dia 460 mm.
n.01 groups cylinder( first group) dia 1280 mm with 5 couples
n.01 doffer ( first group) dia.1230 mm
n.01 peralta
n.01 scotch feed ww
n.01 groups cylinder( second group) dia 1280 mm with 5 couples
n.01 doffer ( second group) dia.1230 mm
n.01 groups cylinder( third group) dia 1280mm with 5 couples
n.01 doffer ( third group) dia.1230mm
n.01 condenser with 168 goo ends , single tape of 10.6 mm.
n.01 carding set, make HARTMAN , ww 1850 mm, 3,5 swift , composed with :
n.01 Hopper feeder with double feeding system
n.01 breast cylinder dia. 720 mm with 4 couples
n.01 cylinder transfer dia 460 mm.
n.01 groups cylinder( first group) dia 1280 mm with 5 couples
n.01 doffer ( first group) dia.1230 mm
n.01 peralta
n.01 scotch feed ww
n.01 groups cylinder( second group) dia 1280 mm with 5 couples
n.01 doffer ( second group) dia.1230 mm
n.01 groups cylinder( third group) dia 1280mm with 5 couples
n.01 doffer ( third group) dia.1230mm
n.01 condenser with 188 good ends , single tape of 9,3 mm.
