42-25 Thermoform Machine

Manufacturer SHAWPAK (RIVER MEDICAL PACKAGING)
Shawpak 42-25 Thermoform Machine
Stepper motor Controlled Rotating tooling drum
Film Mandrel - Single Reel 12.5" (320mm)
76mm (3") Reel Core Diameter
Reel Run-Out Warning
Synchronisation for All Common Feed Systems
Provision for Printer / Coder, Electrical Signal Only
Stainless Steel Top Guard
Operator Interface Mounted on a Swivel Arm
Maximum pack size 420mm x 250mm x 100mm
Mitsubishi L Series PLC
Mitsubishi 7” Colour HMI
Aluminium / Stainless Steel Construction
Acrylic Guard Doors – Allowing full visual of machine when in motion
Machine Feet with Castors
Base Web Digital DC Unwind
Top Web Digital DC Unwind
Standard Flying Knife
Die Cut Station
eWon Connection for remote access (requires direct internet access)
Manual Base Web Splice Table
Manual Top Web Splice Table
Slice Detect Sensor x2
Tooling – To Include: Form Heater, Forming Drum with
silicone inserts (plus 1 spare set) and Sealing Platen
Reject Conveyor for trim waste and reject packs
Mounting Brackets & Print Roller for Thermal Transfer Printers
8.3’’ Bellmark TT Printer Traverse
Power Supply
Voltage: 230v
Phase: Single Phase
Cycles: 50/60hz
Air Supply: 6 bar Minimum – Clean and dry supply
