Andritz De-inking pulp

TECHNICAL DATA
Year of construction : 1986, renewed in 2018
Production Capacity : 100 ton/day
Raw material : recycled paper and broke
Drive voltage : 500 V 50 Hz
DCS : Valmet DNA
Key products : De-inked pulp

MAIN EQUIPMENT
SECONDARY PULPER:
Type : Andritz FibreGuard FG02HR
Power : 90 kW
Year of manufacture : 2018

PRESSURE SCREENS FOR ROUGH SCREENING:
Type : Andritz ModuScreen F30 (1 pcs),
Andritz ModuScreen F10 (1 pcs) and Andritz ModuScreen T2C (1 pcs),
Power : 75 kW, 30 kW and 55 kW
Year of manufacture : 2018

PRESSURE SCREENS FOR FINE SCREENING:
Type : Lamort SPN12 (1 pcs), Lamort SPN7 (1 pcs) and Lamort SPN4 (1 pcs)
Power : 55 kW, 18,5 kW and 11 kW
Year of manufacture : 1985

MASS FLOTATION:
Type : Andritz SelectaFlot SFL1DL
Year of manufacture : 2018

WASHER 1:
Type : Andritz Speed Washer SWd30
Wire width : 3200 mm
Wire length : 11060 mm
Power : 75 kW
Year of manufacture : 2018

WASHER 2:
Type : Black & Clawson Double Nip Thickener, size 200
Wire width : 1910 mm
Wire lenght : 6452 mm
Power : 55 kW

SLUDGE TREATMENT:
Type : Bellmer Kufferath Akupress BX 1100LL-H (1 pcs),
Bellmer Kufferath Sludge Reactor FR-3 (1 pcs),
Bellmer Kufferath Sludge Precipitator AKSE 175/10 (1 pcs)
and Sludge Press Dosing Screw (1 pcs)
Sludge dry-content : ~35-50 %
Year of manufacture : 2017

SCREW PRESS:
Type : Andritz Pulp Screw Press SCP1005
Power : 110 kW
Year of manufacture : 2018

DISPERGER:
Type : Cellwood Krima 710
Power : 400 kW
Year of manufacture : 1992

SPARE PARTS
Washer wires
Andritz Tecnowash M 50/36 for washer 1 (2 pcs)
Andritz Tecnowash M 60/54 for washer 2 (2 pcs)

ACCESSORIES
Include: pumps, tanks, agitators, instruments, valves
