Bausano MD52/23 Plus
EUROPE (Western and Northern)
BAUSANO MD52/23 Plus
for soft and rigid PVC
Construction year 2008
Barrel with 2 x 52 mm diam screws, 23/LD
Rotation speed 14-79
Thrust system dynamic load 410 kN
Torque per screw 1780 Nm
Counter.rotating screws for PVC
more details on request
Fluid-type Thermostating
Vacuum degassing pump
Air cooling
40 kw drive
about 80_100 kg/h
Constructor's description:
Pressure transducer
Multistage and thermocontrolled screws with speed variation
Degassing
Stainless steel double jacket barrel protection
Electronic level for hopper stop
Revolving stainless steel hopper for easy cleaning
Screw conveyor dispenser
Exclusive and patented MultiDrive transmission system
Thrust bearing loading cell with two alarm thresholds
Asynchronous motors connected to an inverter
Screw thermostat control unitThrust bearing with high load capacity
Oil circulation pump with filter and heat exchanger
Touch-screen plc control panel
The machine is offered checked for good condition OR totally reconditioned
Possible addition of air pelletiser or cooling air tunnel + cutting mill.
