Biesse ERGHO 6

Automatic edge banding machine (Used Machine)
Control Panel
Pre-milling unit with 2 diamond cutters. (After replacing the dia cutters only 1x)
Banding unit with coating using roller for EVA granular adhesives
Pressure unit with presser rollers 1+3 to ensure a firm and even glue of the edge to the part.
Pneumatic dripping knife for rough cutting of the edge with overlap
A drip unit with two hooded chainsaws for precise cutting of the edge overlaps.
Tiltable saws.
Coarse milling unit double-engine for rough overhanging from the top and bottom of the part.
It saves the blade of radius milling machines.
Adjustable inclination.
Slots can be milled.
Longitudinal and rostering twin-engine unit for rounding edges including corners. Setting up R.
Profile cidlines R2.
Surface cidlines
Polishing unit with 2 discs, for cleaning the joint by cidlin
The machine was regularly serviced
Instructions in Czech.

TECHNICAL PARAMETERS OF THE MACHINE:
Part thickness: 10 - 45 mm
Edge thickness: 0.4 - 3 mm (Max. edge thickness of solid treating15×45 mm)
Minimum width of the part: 50/80 mm (with a length of 250/150 mm)
Feed speed: 10 - 18 m/min.

DIMENSIONS AND WEIGHT OF THE MACHINE:
Dimensions for transport: 6020×1450×1450 mm
Working surface height: 900 mm
Weight: 2100 kg
