Breitner SRT Food line Filling Line

Machines:
Pos. 1 Bottle unscrambler Breitner BFC 8002 (2013)
Pos. 2 Filling machine Breitner MDL 2086 (2013)
Pos. 3 Rotary capping machine Breitner SRT 5044 (2013)

Conveyor systems:
several conveyors included.

All conveyors:
Chain width: 82,5 mm
Belt housing: stainless steel AISI 304
Belt guide: plastic c-profile, 2-fold and stainless steel rods
Chain material: Delrin steel
The unclosed bottles are protected of falling dirt by a roof made of plexiglas over the conveyor.

Bottle formats:
Our service: send us your requirements and we will check the possibility of processing your bottle format.

Cap formats:
Screw caps, press-on caps, spray pumps with riser pipes
Our service: send us your requirements and we will check the possibility of processing your cap format.

Capacity:
Unscrambler: max. 6.000/h
Filling machine: max. 5.000/h
Rotary capping: max. 5.000/h
The output depends on the container and cap geometries and the filling product.


1. Bottle Unscrambler BREITNER BFC 8002

Operation: continuous from supply bin
Bin volume / drum Ø: 1.4 m³ / 1500 mm
Working height: 900 mm, left → right
Material / Housing: AISI 304 stainless steel + plexiglass
Safety: door switches, overload protection
Power / Air: 3 × 400 V, 4 kW / 400 Nl/min at 6 bar
Container size: round Ø ≤100 mm × 250 mm, larger on request
Feature: blow-cleaning station with ionized air and dust extraction

2. Filling Machine BREITNER MDL 2086

Filling: mass flow, 8 stations (expandable to 12)
Filling range: 100 – 2000 ml/g, up to 5,000 bottles/h
Working height / direction: 900 mm, left → right
Product-contact parts: AISI 316, food-grade hoses, VITON seals
Tank / Pressure: 100 L, 5 bar
Power / Air: 3 × 400 V, 4 kW / 150 Nl/min at 6 bar
Container size: H 50–350 mm, Ø/width 50–80 mm, various shapes
CIP cleaning: 8 cleaning cups, automatic spray & drain, multi-step program
Extras: laminar flow, remote maintenance, additional filling valves, swiveling tray, heating system

3. Rotary Capping Machine BREITNER SRT 5044

Operation: continuous rotary, 4 capping stations
Output: up to 5,000 containers/h
Container size: Ø ≤100 mm, H ≤300 mm
Working height / direction: 900 mm, left → right
Drive / Tools: servo motor, 0,3-3,5 Nm; BREITNER capping tools
Power / Air: 3 × 400 V, 4 kW / 100 Nl/min at 6 bar
Control: B&R controller, touchscreen, 200 format memories, password-protected Safety & inspection: door switches, overload, “No bottle – no closure,” optical cap check, reject system
Extras: servo vertical movement, torque monitoring, fan-based cap feed, vibratory sorter VIB 8001, cap supply SFB 8001
