Butfering SWT

Wide Belt Sander
All-round sanding system for veneer sanding, lacquer sanding, and texturing
Well-maintained machine, only approximately 360 operating hours!
Working width 1350 mm
Workpiece thickness 3 - 160 mm

Equipped with:
1x cross sanding unit with articulated pressure beam, 13.5 kW, frequency-controlled 2-16 m/s
1x combination unit with steel roller, 18.5 kW, frequency-controlled 2-18 m/s.

Sanding belt dimensions 1370 x 2150 mm.
1x brush sanding unit, synchronous and counter-rotating, with oscillation, 15 kW, diameter 300 mm. Current structuring brush attachment.
1x brush unit, 5.5 kW, diameter 150 mm.
Current equipment: Anderson K80
Ionization system with 16 rotating nozzles for workpiece cleaning
Infinitely variable feed rate, approx. 2.5 - 13 m/min.
Conveyor belt with vacuum, 5.5 kW
Touchscreen control
Including various sanding belts
Machine dimensions: approx. 2600 x 2100 x 2000 mm
Weight: approx. 5500 kg
