Challenge, CP Bourg BB3002/CMT-330B

Specifications:
MEDIA :
Maximum speed 650 cycles/hour – 350 books/hour

COVER :
Minimum cover size 100 x 201 mm (3.93 x 7.91 in)
Maximum cover size 385 x 750 mm (15.15 x 29.52 in)
Cover weight 80 to 300 gsm

CONTENT:
Minimum paper size of books with cover (perfect binding mode) 100 x 90 mm (3.93 x 3.54 in)
Maximum paper size of books with cover (perfect binding mode) 385 x 380mm (15.15 x 14.96 in)
Minimum paper size of books without cover (padding mode) 60 x 90 mm (2.36 x 3.54 in)
Maximum paper size of books without cover (padding mode) 385 x 320 mm (15.15 x 12.59 in)
Book thickness 1 to 60 mm (0.04 to 2.36 in)
Milling depth 0 to 3 mm (0 to 0.11 in)
Paper weight 60 to 160 gsm

PHYSICAL :
Dimensions BB3002 (L x W x H) 202 x 135 x 150 cm – (79.52 x 53.15 x 59.05 in)
Dimensions BBR (L x W x H) 106 x 60 x 50 cm (41.73 x 23.62 x 19.68 in)
Weight BB3002 650 kg (1,430 lbs)
Weight BBR 80kg (176 lbs)
Glue temperature 130 to 180 °C (266°F to 356 °F)
Cover station capacity / cover pile height 80 mm (3.15 in)
BBR capacity 700 mm (27.56 in)
The new Challenge CMT 330 has expanded capability to finish cut LANDSCAPE FORMATTED BOOKS
up to 12.1” (307 mm) tall by 12.9” (328 mm) wide and down to 5.875” (149 mm) tall by 3.937” (100 mm) wide.
Designed and built in Michigan-USA, the CMT 330 utilizes powerful hydraulic cutting and clamping pressure to effortlessly cut up to a 2” (50.8 mm) thick book.
