CMU 1250x30 30 ton (max 40 ton)

Ref : 2793292-3-MT

Condition : Used

Manufacturer : CMU

Model : 1250x30

Pressure : 30 ton (max 40 ton)

Year(s) : -

Quantity : 1

Location : Seller or machines location:
-

Press force 30 ton (max 40 ton)
Bending length 1250 mm

Control Cybelec DNC 60
4 axis CNC (Y1 / Y2 / X / R)
Laser safety system for fast descent
European type tooling with quick punch clamping
Backgauge X / R axis

Distance between uprights 1070 mm
Throat depth 410 mm
Working height 800 mm
Max distance between table and ram 455 mm
Ram stroke (Y1 / Y2) 215 mm
Backgauge travel (X) 1000 mm

Fast approach speed 160 mm/s (with laser)
Working speed 10 mm/s
Return speed 130 mm/s

Electrical supply 3 phase + N + PE

Machine dimensions 1900 x 1600 x 2250 mm
Machine weight 2600 kg
