CNC (FANUC 0I-TF PLUS CNC COLOR CONTROL) 1,200 RPM SMART NL6000 XLM 3 Axis

X1-Axis Travel: 18.7"
Z1-Axis Travel: 129.92"
C1-Axis Travel: 0.001
Rapid Traverse Rate - X1: 630 in/min
Rapid Traverse Rate - Z1: 394 in/min

Swing Over Bed: 40.55"
Machining Length: 125.98"
Distance Between Centers: 129.92"
Chuck Size 1: 24"
Spindle Nose 1: A1-15
Spindle Bar Capacity 1: 6.5"
Turning Diameter, Shaft Diameter: 35.43"
Spindle Speeds 1: 1,200 RPM
Spindle Horsepower 1: 73 hp
Spindle Bore Diameter 1: 7.125"
Spindle Torque: 3792
Gear Ranges: 2
Turret Configuration 1: 1285
Turret Rotary Tool Spindle Speed 1: 3,000 RPM
Turret Rotary Tool Horse Power 1: 20 hp
Tailstock Quill Diameter: 7.09"
Tailstock Taper: MT 6
Tailstock Quill Travel: 5.91"
Tailstock Travel: 124.02"
Live Tooling: Yes
Weight: 44,754 lbs
Chip Conveyor
24" 3-Jaw Hydraulic Chuck System
0.001 C-Axis Indexing
(1) O.D. Tool Milling Holder
(2) I.D. Tool Milling Holder
Chuck Clamp Confirmation
Manual Steady Rest and Steady Rest Base 1.19" ~ 12.9"
Programmable Tailstock & Quill with Built-In Live Center
Auto Tool Setter
Inch/Metric
High Pressure Coolant Pump
