CNC Plasma Cutting Machine – For Chimney and Ventilation Production CNC CONTROL

Cutting pipe diameter: Ø60 mm – Ø600 mm
Max. workpiece length: 1500 mm
Sheet thickness (official): 0.5 – 1 mm
Tested cutting capability: up to 3 mm
Plasma sources: 2 units – 60A and 80A
Plasma power: 60 A / 80 A

Fully programmable CNC-controlled machine
Ability to generate cutting contours from a model or template
Precise automatic positioning and rotation system
Adjustable for various pipe diameters
Integrated plasma cutting control system with adjustable power
Equipped with two plasma sources (60A and 80A) for flexibility in production
Suitable for production of ventilation systems, chimney elements, ducts, and various tubular structures
High cutting accuracy and repeatability
Reduces the need for manual labor
