Colt CERFS-35-30 Max Coil Weight: 12,000 lb

Max Coil Width: 30"
Max Coil Thickness: 0.060"
Coil OD: 60"
Coil ID Range: 19" - 25"

CHDRD-1200-30 Heavy Duty Powered Double End Uncoiler
Max Coil Weight Per Side: 12,000 lb
Max Coil Width: 30"
Max Coil OD: 60"
Coil ID Range: 19" - 25"

CKT-1200-30 Heavy Duty Traveling Coil Car
Max Coil Weight: 12,000 lb
Max Coil Width: 30"
Max Coil OD: 60"

CPTT-30 Pivot Style Threading Table
Extendable Peeler Blade

CERFS-35-30 Feeder/Straightener
Max Coil Width: 30"
Max Coil Thickness: 0.060" @ 30" Width
Minimum Material Thickness: 0.015"
Maximum Feed Length: 0.005" - 999.999"
Distance Between Roll Centers: 4.875"
Maximum Speed: 110 FPM
Accuracy: ±0.002"
Entry Pinch Rolls: 2
Exit Pinch Rolls: 2
Pinch Roll Diameter: 3.5"
Straightening Rolls: 9
Straightener Roll Diameter: 3.5"
Alligator Style Feeder Straightener Head

CMPS-30 Production Shear
Maximum Material Thickness: 0.080" @ 30" Width
Hydraulic Down Cut
Maximum Stroke: 4"
Cycle Time: 5 Cuts/Min

PAX Roller Lubricator
Model: CAB486

CMMSF-30 Magnetic Servo Blank Conveyor

Coil Car
Powered Double End Uncoiler
Traveling Coil Car
Threading Table
Feeder/Straightener
Production Shear
Roller Lubricator
Magnetic Servo Blank Conveyor
