Dimeco Microfeed 1125-D Simo Star 510 x 6.35 mm
Ref :
2750895-3-CP
Condition :
Used
Manufacturer :
Dimeco
Model :
Microfeed 1125-D Simo Star
Capacity :
510 x 6.35 mm
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
Maximum width: 510 mm
Maximum thickness: 6.35 mm
Maximum thickness for maximum width: 5.5 mm
Maximum cross-section area: 2800 mm²
Roll diameter: 125 mm
Maximum speed: 120 m/min
Maximum feed cycle: 300 mm
Peak motor torque: 20 Nm
Weight: 440 kg
Features / Equipment
Microfeed unit
2 rolls Ø125 mm driven by precision cluster gear set
AC brushless servo drive with resolver feedback
Anti-backlash gear worm reducer
Adjustable roll pressure by air regulator
