Doosan DNM 4500 3 Axis

X-axis travel: 800 mm
Y-axis travel: 450 mm
Z-axis travel: 510 mm
Rapid traverse (X/Y/Z): 36 m/min
Control: Heidenhain TNC620
Table size: 1000 × 450 mm
Maximum table load: 600 kg
Spindle speed: 0–12,000 rpm
Spindle motor: 10–17 kW (S6-25%)
Spindle taper: SK40
30-position tool changer
Machine dimensions: Approx. 2160 × 2615 × 2950 mm
Machine weight: Approx. 5000 kg
Electronic handwheel
Chip conveyor
Renishaw OTS tool setter
Receiver for Renishaw 3D probe
Spindle cooler
4th-axis preparation
Approx. 30 SK40 tool holders
Original documentation
