Drent VSOP 850 Variable 8

Web Offset Press
Max Web Width: 850 mm
Max Print Width: 840 mm
Max Speed: 300 m/min*

Power: 400V 3 phase, 50 Hz
Substrate Thickness: 10 – 350 micron
(depending on the substrate)
Printing Processes: Offset and Flexo
* Subject to substrate, ink coverage and tack of ink

Comprising of:
(1) Serame Unwind Stand
• Max reel ø1270 mm
(1) Infeed
• Integrated web guide
(1) Kelve Anti Static Dust Extraction Device
(1) Arcotec Double Sided Corona Pre-Treatment Station

(8) VSOP 850 Offset Printing Units
• Size range 15 – 30”
• Remote ink duct control
• Ink oscillator cooling
• Baldwin blanket washing

(8) Ink Agitators
(8) Ink Mist Hoods
• Suction Device

(1) Flexo Insert for VSOP Offset Tower

(1) 3 Roll Chill Stand
• Integrated UV lamp support

(1) IST UV Drying System
• 9 lamp system
• Lamps can be positioned after units 2, 4, 7 & 8

(2) Air Loaded Turner Bars
• After Printing Units 2 & 4

(1) Tension Control Unit
• Web edge trimming
• Longitudinal perforation
• Closed loop automatic tension control

(1) Serame Rewinder
(1) Technotrans Dampening Recirculation Unit
(1) Technotrans W/W Heat Exchanger
• Chill roll and ink oscillator cooling
(1) IST A/W Heat Exchanger for UV Lamp Cooling
(1) Eltromat DGC 650 Register Control System
(1) Eltromat Imcon-3 Remote Ink Duct Control and Web Video
(1) Main Control Desk
(1) Drent Goebel Main Electrical Control Cabinet and Drive System
(1) IST Main Electrical Control Cabinet
(1) Eltromat Main Electrical Control Cabinet
(1) Plate Bender
(1) Sleeve Service Station
(1) Set of Manuals & Drawings
