Durma HAP 30.120 120 t

Press force: 120 t
Bending length: 3050 mm
Distance between columns: 2550 mm
Upper beam stroke: 155 mm
Throat depth: 350 mm
Adjustment speed: 100 mm/sec
Working feed speed: 9.0 mm/sec
Return speed: 77.0 mm/sec
Control: P40 NC
Maximum working height: 878 mm
Table width: 104 mm
Oil volume: 150 l
Total power requirement: 11.0 kW
Machine weight: 7550 kg
Machine dimensions: 3550 x 2150 x 2600 mm

NC electro-hydraulic press brake
NC-controlled axis Y1
NC-controlled axis Y2
NC-controlled axis X
Electro-motorized backgauge
Manually adjustable stop fingers
Backgauge lateral adjustment
Backgauge height adjustment
Split upper tooling set
Multi-V bottom die block
Lateral safety guards
Rear safety guard
Two-hand foot control
Operating instructions
