Eldorado M75 KNEE TYPE 11,740 RPM

Table travels 18" X, 16" Y, 10" Z
Working surface of table 12" x 42"
Drilling capacity .055" to 1"
Spindle travel 30"
Variable spindle speeds 1440–11,740 RPM
Variable spindle feed rate .1–99.9 IPM
Rapid traverse and return rate 200 RPM
High-pressure coolant system 1500 PSI
Coolant flow 18 GPM
Coolant tank 90 gallons
Coolant pump motor 7.5 HP
Machine dimensions approx. 4' x 8' x 7.5' h
High-pressure coolant dimensions 3' x 6' x 3' h
Weight approx. 5000 lbs

3 HP main motor
Flo-Minder
Feed thrust meter
Automatic lubrication system
Riser fixture 12" x 42" x 13" h
