Estarta 301 MV

Ref : 2625002-3-MT

Condition : Used

Manufacturer : Estarta

Model : 301 MV

Year(s) : -

Quantity : 1

Location : Seller or machines location:
EUROPE (Western and Northern)

ESTARTA 301 MV

Dimensions 1520x1020x1260mm
Weight 1550 kg
Grinding wheel gap 1.5/50mm

Max.width of wheel in feed grinding 125mm
Working wheel dimensions (od x id x width) 300x125x175mm
Øext.min. working wheel 220mm
Max. profile depth of the working wheel 8mm

Driving wheel dimensions (od x id x width) 220x125x125mm
Øext.min. driving wheel 165mm
Working wheel motor power 7,5Kw
Driving wheel motor power 0,75Kw

Angle of inclination of the working grinding head +/- 5º
Angle of inclination of the drive wheel head -2/+5º
