FOR.A HVS-2000
AMERICA North (USA-Canada-Mexico)
Video Formats:
1080i 59.94/50
1080PsF 29.97/25/24/23.98
720p 59.94/50
525 59.94 (NTSC)
625 50 (PAL)
Optional: 1080p 59.94/50 (Level-A)
Video Inputs
24 x BNC, 75 Ohms (HD-SDI: 1.5 Gb/s; SD-SDI: 270 Mb/s)
Expandable to up to 48 x SDI with 6 x HVS-100DI-A cards (available separately)
Video Outputs
16 x BNC, 75 Ohms (HD-SDI: 1.5 Gb/s; SD-SDI: 270 Mb/s)
2 x HDMI
Expandable to up to 20 x SDI and 2 x HDMI (via separately available expansion cards)
Still Store
4 x Channels with 900 frames at 1080 resolution, approx. 30 sec at 1080i
Expandable to up to six channels with 1800 frames at 1080 resolution, approx. 1 minute at 1080i (expansion cards available separately)
Multiviewer
2 x Channels, expandable to four channels (64 windows) via expansion cards (available separately)
2/4/5/7/9/10/11/13/16-way split views with title, tally, audio level meter, safety area, and border display
Processing Amplifier
On all inputs/outputs
Color Correction
4 x Channels (two channels per M/E)
Expandable to up to 12 channels via expansion cards (available separately)
Event Memory
100 events (cross-fade transition available when loading events)
Macros
100 Macros:
00 to 89: 30 actions max.
90 to 99: 300 actions max.
Power Consumption
At 100 to 120 V: 496 W
At 220 to 240 V: 476 W
Weight
39.7 lb / 18 kg
