Format4 H 50 5-axis

5-axis CNC machining center
Used machine
X-axis working area: 3,740 mm
Y-axis working area: 1,570 mm
Z-axis working area: 350 mm
4th axis: Yes
5th axis: 5-axis spindle, 12 kW with additional C-axis locking

Tool changer positions: 24 with disc changer; 10 in the machine stand on the left
Vertical drilling spindles: 12
Machine table: Console table
Automatic table positioning: Yes
6 e-motion workpiece supports
Special workpiece clamping system: For frames
Software: FORMAT 4 WOOD FLASH, TPA ALBATROS
Includes: 12 frame clamps, 8 large and 4 medium suction cups

2 machining areas for pendulum loading
With automatic central lubrication
With mobile control panel with PC monitor
With air conditioning for control cabinet
With 90 m³/h vacuum pump
With handheld control unit
