Fully Automated Fibre Filling System
EUROPE (Western and Northern)
System Components & Specifications
• Automatic Feeding Machine: 5500 × 1400 × 2300 mm | 1400 kg | 4.8 kW
• Fibre Opening Machine: 1800 × 1220 × 1050 mm | 750 kg | 6.05 kW
• Fan Conveying Machine (x2): 670 × 650 × 1350 mm / 950 × 600 × 910 mm | 60–90 kg | 2.2 kW each
• Storage Box (8 m²): 2700 × 1300 × 2750 mm | 650 kg | 3 kW
• Filling Machine #1: 1950 × 850 × 2050 mm | 650 kg | 3.7 kW - 2 nozzles
• Filling Machine #2: 1950 × 850 × 2051 mm | 651 kg | 4.7 kW - 2 nozzles
• Control Panel / Board
Key Features
• High-efficiency fibre filling system designed for high-volume production
• Automatic feeding conveyor accepts up to 250 kg of uncarded fibre
• Long-tooth and multi-tooth rollers create light, airy fibre
• Large 8 m² storage box supports continuous output for up to four operators
• Suitable for filling pet beds, cushions, plush toys, and more
• Interchangeable filling nozzles for different product requirements
• Power: 26 kW
• Voltage: 380V, 50Hz, 3-Phase
• Productivity: Up to 1,500 kg/hr
• Compressor Required: ">8 kW at 8 bar
