Garant TRIUMPH 3G/SERVO

Product: Block bottom bag making machine for producing 1-ply and two ply SOS bags with Window
Material: Kraft paper (1 layer): 70-180 grs
Performance rating: according to materials, bag sizes and operator’s skill
Unwinder: max roll diameter of 1300 mm with inner core diam. of 76mm
Max paper roll width: 1100 mm
Bag widths: 105 – 320 mm
Bottom widths: 55 – 180 mm
Bag cutting lengths: 240 – 650mm
Power consumption: electrical energy: approx. 130 kVA
Compressed air consumption: approx. 50 Nl/min.
Air pressure: 6 – 8 bar
With Two-ply unit for producing 1-ply and two ply bags
With die-cut Window Unit
