GM DC 350 Screen printing machines

1 Unwinder
1 Web Guide
Min. web width 50 mm
1 Flat Bed Hot Flow Press Unit, 30 tons
Servo Drive System ensures consistent pressure and embossing time at all speeds
Integrated foil saving function
Swivelling foil tower can be used on both sides
A single module for blind embossing and/or flatbed hot foil
The system uses magnesium, brass/sheet metal or polymer plates
Plates can be changed while hot using a carriage system
Speed 6000/H embossing or 10-15m/min
Web width 110mm - 330mm
Substrates 50-200um
Label paper 60-120 g.
UPM Vellum natural wine paper. RAFLACOAT RP48AT semi gloss paper
All other substrates must be tested by GM
Polymer (blind embossing ONLY)
Sheet thickness: 5-10mm. 7mm is standard
Backing plate, self-adhesive rubber (1-3mm). SH65
Plate size and type 304.8 x 330mm. 5-9mm magnesium
Plate pressure 30 tonnes
Foil feed transverse and longitudinal direction (rotating tower)
Temperature contr. 80°-130° C
Heating time 20 min.

SCREEN PRINTING UNIT
Speed 4000/h overlays or 5-15 m/min.
Web width 110mm - 330mm
Frame size 660mm x 500mm
Frame type 30mm x 30mm aluminium frame
Print area 330mm (length) x 330mm (width)
Servo register system for print marks or optional label distance sensor
Pneumatic squeegee with servo movement

1 Rewinder
Rewinder for roll diameters of Ø600mm (depending on job/material)
Electronic control of speed, position and torque
Automatic control of the rewind tension for every speed and all rewind diameters
Pneumatic replaceable rewind shaft Ø 76 mm
Inner and outer winding
