Haas CNC CONTROL 3400 RPM SL20 2 Axis

Ref : 2765114-3-CP

Condition : Used

Manufacturer : Haas

Controller : CNC CONTROL

Spindle Speed : 3400 RPM

Model : SL20

Nb Of Axis : 2 Axis

Year(s) : 2005

Quantity : 1

Location : Seller or machines location:
AMERICA North (USA-Canada-Mexico)

X-axis travel 9.0″
Z-axis travel 20.0″
Max turning diameter 10.3″
Max turning length 20.0″
Swing over front apron 31.75″
Swing over cross slide 20.00″
Bar capacity 2″
Max spindle speed 3400 RPM
Spindle nose A2-6
Spindle bore 2.312″
Spindle motor 20 HP
Spindle torque 150 ft-lbs at 600 RPM
Max cutting feed 500 IPM
Chuck size 8″
Chuck type 3-jaw hydraulic
Turret stations 10-station bolt-on
Machine dimensions 112″ x 64″ x 73″
Machine weight 7500 lbs
