Haas VF-2SS 5 Axis

X-axis travel: 30" (762 mm)
Y-axis travel: 16" (406 mm)
Z-axis travel: 20" (508 mm)
A-axis tilt: ±120°
B-axis rotation: 360° continuous

Rapid traverse: 1400 IPM
Control: Haas control
Spindle speed: 12000 RPM
Spindle motor: 30 HP
Spindle drive: Inline direct drive
Spindle taper: CT40
Tool magazine capacity: 24 ATC
Maximum tool diameter: 3.0"
Maximum tool weight: 12 lbs
Table size: 36" x 14"
Table load capacity: 1500 lbs
Platter diameter: 6.3" (160 mm)
Maximum workpiece weight: 80 lbs (36 kg) including fixture
Maximum part swing: 10.5" (267 mm)
T-slots: 6 slots, 8 mm
Machine dimensions: 89" x 92" x 104" H
Machine weight: 8000 lbs

Haas 5-axis drives and wiring
Haas model TR160 CNC trunnion table
Rigid tapping
Rotation and scaling
Quick code
Spindle orientation
Extended memory
User-definable macros
DNC enabled
Advanced tool management
Intuitive part programming
Renishaw wireless intuitive tool and part probe (WIPS)
Coolant system
24 + 1 tool side-mounted tool changer
