Haas VF-9/40 3 Axis

X-Axis Travel: 84′′
Y-Axis Travel: 40′′
Z-Axis Travel: 30′′
Rapid Traverse X/Y/Z: 600 IPM
Control: HAAS CNC Control
Rigid Tapping
Macros
Rotational & Scaling
M19 Spindle Orientation
4th Axis Enabled
16 MB Memory Option
Flood Coolant Nozzles
Table Size: 84′′ × 36′′
Table Load Capacity: 4,000 lbs
Spindle Nose to Table: 4′′ – 34′′
Spindle Speed: 10,000 RPM
Spindle Power: 30 HP
Spindle Taper: CAT 40
Automatic Tool Changer: 24+1 Side-Mount ATC
24 Position Side-Mount Tool Changer
Maximum Tool Diameter: 3.5′′
Maximum Tool Weight: 12 lbs
3.5′′ Floppy Disk Drive
Chip Auger
Machine Dimensions: 214′′ × 124′′ × 128′′
Machine Weight: 28,260 lbs
