Hardinge XR760 3 Axis

Axis travels XYZ: 760 x 610 x 610 mm
Rapid feedrates XYZ: 43 x 43 x 36 m/min
Maximum cutting feedrate: 20000 mm/min
Control Heidenhain iTNC640
Coolant
Interlocked guards
Low volt light
Remote hand wheel
Swarf conveyor
Through spindle coolant
Spindle motor power: 18.5 kW
Spindle speed: 12000 rpm
Table size: 900 x 600 mm
T-slots: 5 x 18 mm
Tool change capacity: 30 station
Tool change time (chip to chip): 4 seconds
Tool size: BT40
Maximum tool diameter: 85 mm
Maximum tool diameter with empty adjacent pockets: 125 mm
Maximum tool length: 300 mm
Maximum tool weight: 7 kg
Maximum workpiece weight: 700 kg
Min - max height under spindle: 100 - 710 mm
Machine dimensions: 2844 x 3000 x 2921 mm
Machine weight: 6750 kg
