Harris Coat ZR30 Coater Surface (Sheet)

Max. sheet size: 762 x762 mm
Min sheet size: 152x152 mm
Drying system: Infra Red + UV
Max. speed: 67 Meters per minute
Coating system: Gloss UV, High Gloss UV , Matte UV , Specialty UV , AQ (with optional IR Dryer)
Automatic setting time 5 minutes
automatic washing time 10 minutes
Automated Set-up Time 5 Minutes
Automated Wash-up Time 10 Minutes
8.5” x 11” / 215 mm x 280 mm sheets width 12,700 sheets/hour
12” x 18” / 305 mm x 450 mm sheets width 9,900 sheets/hour
14” x 21” / 355 mm / 530 mm sheets width 8,800 sheets/hour
21” x 30” / 530 mm x 750 mm sheets width 6,300 sheets/hour
28” x 40” / 710 mm x 1020 mm sheets width 5,000 sheets/hour
Painting speed 4,600 B2/hour
anilox rollers for the machine 3;9;12;18
Automated Set-up Time 5 Minutes
Automated Wash-up Time 10 Minutes
UV drying
IR drying (suitable for dispersion varnish and primer for HP Indigo)
kit for processing thin materials
varnish application using a chamber doctor blade
high feeder
2 independent varnish circuits with automatic washing
Anti-Ghost system
innovated sheet delivery system
