Heidelberg XL 106-8-P 18k 750 × 1,060 mm

Equipment:
Machine Control
Control Unit: Prinect Press Center XL 3
Quality Control: Prinect Inpress Control 3 (2 measuring bars, for perfecting from P5)
Wallscreen XL
Speedmaster Operating System
Intellistart 3 with Performance Package and Wallscreen XL
Color Fast Solution
Air Assistant
Wash Assistant
Device Assistant
Press Center 3/XL 3 Instant Gate
Press Center 3/XL 3 Color Assistant Pro
Press Center XL 3 Wallscreen Application
Press Center XL 3 Netprofiler

Feeder:
Feeder type: Preset Plus Feeder
XL sheet arrival system
Ultrasonic double sheet control
Pull-gauge double sheet control
Electromechanical shingling control
Package control
Intercom system
Feeder pile plate retractable

Printing Units:
Number of printing units: 8x
Perfecting: 4/4 (perfecting position between unit 4 and 5)
Fully automatic three-drum perfecting system
Plate changing: AutoPlate XL 3 (simultaneous plate change at all units)
PerfectJacket
Sheet travel monitoring in all units
Variable AirTransfer system
Low-maintenance universal gripper system
Patented wing grippers and gripper bridge spoilers
Fully automatic preset air settings for all sheet guiding elements
Blanket washing device: program-controlled with lightweight tuch modules and automatic coupling
Impression cylinder washing device: program-controlled
Additional impression cylinder washing insert for DW/LW
Saphira Blanket Pro 100 (per printing unit)
Mechanical hickey catcher with zone scale
Roller-Check-Assistant

Inking and Dampening:
Inking/dampening unit: Heidelberg Hycolor
Separate ductor tempering
Remote-controlled short inking unit switching
Roller group separation
Remote rider roller adjustment
Hycolor Pro film dampening unit (5 rollers)
Longlife chrome dosing rollers
Fully automatic ink roller washing device (12 wash programs)
Roller protection system Auto Protect
CombiStar CAN (water-cooled)
FilterStar Compact
Digidos P 150 + Sonden retrofit (fountain solution dosing with pH probe and conductivity measurement)

Delivery:
Delivery type: Preset Plus Delivery
Delivery extension: X1
Preset-controlled suction segment discs
Sheet brake system with preset-capable brake modules
Dynamic sheet brake
Pile plate in delivery with ramp
InsertStar (drive-side strip feeder with counting function and waste marking)
CleanStar for delivery extension

Powder Device:
PowderStar AP 500 Duo CAN

Periphery:
AirStar Pro (water-cooled)
ScrollStar
StaticStar Compact (antistatic system)
Automatic central lubrication
Acoustic package (82–83 dB(A))
Narrow setup variant AS (with sub-frame for elevated periphery on non-elevated machines)

General:
Performance Package (18,000 sheets/h)
Conventional operation (conventional ink and coating systems)
Electronically regulated sine synchronous main drive (efficiency up to 95%)
Standby function
Thin stock package for perfecting machines
HEI ECO package

Technical Details :
Parameter Value
Max. Speed 18,000 sheets/h
Max. Sheet Size 750 × 1,060 mm / 29.53 × 41.73 in
Min. Sheet Size (straight) 340 × 480 mm / 13.39 × 18.90 in
Min. Sheet Size (perfecting) 410 × 480 mm / 16.14 × 18.90 in
Max. Print Size (straight) 740 × 1,050 mm / 29.13 × 41.34 in
Max. Print Size (perfecting) 730 × 1,050 mm / 28.74 × 41.34 in
Plate Size 811 × 1,055 mm / 31.93 × 41.54 in
Stock Thickness 0.03–0.8 mm / 0.0012–0.031 in
Max. Stiffness (DIN 53121) 130 mNm / 1.15 ibf in
Gripper Margin 10–12 mm / 0.39–0.47 in
Max. Pile Height Feeder 1,320 mm / 51.97 in
Max. Pile Height Delivery (front) 1,295 mm / 50.98 in
Max. Pile Height Delivery (side) 1,275 mm / 50.20 in
Max. Pile Weight (Feeder / Delivery) 2,000 kg / 4,410 lbs
Noise Level 80–84 dB(A) (EN 13023)
Voltage 400 V / 50 Hz
Light Voltage 230 V
