Hera SML 3020 x 4.0 Sheet width: 3020 mm

Plate thickness: 4.0 mm
Opening width / upper beam: 350 mm
Adjustment folding beam: 100 mm
Adjustment of lower beam: 80.0 mm
Max. bending angle: 130°
Max. work height: 900 mm
Control: SIEMENS OP 7
Voltage: 400 V
Total power requirement: 9.5 kW
Weight: 5400 kg
Range L-W-H: 4300 x 2400 x 1780 mm

Features

SIEMENS - PLC control model OP 7
Selectable fully automatic or semi-automatic bending process
Bending angle adjustment electronically preselectable 0-135°
Electr. / controlled backgauge X = 1000 mm
Large sheet metal support surface
Heavy welded construction
All drives via worm gear
Motorized adjustment of the bending beam
Large adjustment range of the cheeks
Hydraulic upper tool clamping
Insert / bending tools
Operation manual
Separate split goat foot splint H 170 mm
