Horizon SL5500S with 3 VAC 1000 Towers

Condition Used
Maximum Sheet Size 13.77″ W x 19.68″ L
Minimum Sheet Size 5.52″ W x 7.84 L
Sheet Weight Range Normal: 64 to 210 gsm / Coated: 80 to 210 gsm
Maximum Booklet Size (before trim) 13.77″ x 9.84″
Minimum Booklet Size (before trim) 5.52″ x 3.9″
Trim Width 0.08″ to 1″
VAC-1000 Number of Bins 10
Sheet Feeding System Suction Rotor System
Max. Sheet Size 13.77” W × 19.68"L
Min. Sheet Size 5.83” W × 5.83” L
VAC-1000 Sheet Weight Range:
Art / Coated Paper : 73.3 to 207 gsm
Normal Paper : 52.3 to 207 gsm 8-page fold signature : up to 104.7 gsm
Bin Stack Height Max.Stack Height 2.16" Max. Stack Weight 24.3 lb each bin
Sheet Overlap Front delivery : 4 Steps Maximum, Large, Middle and Small Rear delivery : 4 Steps Maximum, Large, Middle and Small
VAC-1000 Production Speed: 10 bins Max. 9,900 sets per hour (A5LEF, Straight Receiving) Max. 8,900 sets per hour (A4LEF, Straight Receiving)
Bin Production Speed limited by the type of finisher or sheet weight.
20 bins Max. 6,900 sets per hour (A4LEF, Straight Receiving)
30 bins Max. 6,400 sets per hour (A4LEF, Straight Receiving)
Electrical Single Phase 208 / 220 V, 50 or 60 Hz Single Phase 230 to 240 V, 50 or 60 Hz
