Horizon SPF-200A

Condition Used
Sheet Size Max.: 14" x 20" Min.: 4.725" x 7.090"
Sheet Weight Range Normal Paper: 64 to 157 gsm Art Coated Paper: 84.9 to 157 gsm
Stitch Thickness Top/Side Stitch, Corner Stitch and Fold Max. 0.155” (About 48 sheets of normal paper 64 gsm)
Production Speed:
Max. 4,000 booklets per hour (A4-Finish, Portrait)
Max. 4,500 booklets per hour(A5-Finish, Portrait)

Air-Suction Collator VAC-1000 Number of Bins 10 Bins/20 bins/30 bins/40 bins/50 bins/60 bins
Max.Sheet Size 13.77” x 19.68”
Min. Sheet Size 5.83” x 5.83”

Vac 1000 Sheet Weight Range:
Coated Paper: 74 to 210 gsm or 20 to 55 lb
Normal Paper: 53 to 210 gsm or 14 to 55 lb; 8-page fold signature: up to 105 gsm or 27 lb
Bin Pile Height Max. 55 mm or 2.16”
Sheet Overlap 4 Steps

Vac 1000 Production Speed:
Max. 9,900 sets per hour (A5LEF, Straight Receiving)
Max. 8,900 sets per hour (A4LEF, Straight Receiving)
Production speed is limited by the type of finisher or sheet weight
