HydMech S-20H Engine Lathe SemiAutomatic

Capacity 13" W x 18" H
Round Bar Diameter 13"
Mitering 0 to 45 Degrees
Capacity at 45 Degrees 3" x 10-3/4"
Round at 45 Degrees 12"
Capacity at 30 Degrees 13" x 7-3/4"
Round at 30 Degrees 8-1/2"
Blade Speed 90/140/220/310 SFM
Blade 1" x .032" x 13'6"
Blade Guides Carbide Inserts
Blade Wheel Diameter 16"
Work Load 5,000 Lbs.
Table Height 30"
36" In-Feed Roller Table and a 19" Out-Feed Table
Coolant Pump
2.4 Gallon Coolant Reservoir
Hydraulic Cylinder Fed Head Up/Down
Hydraulic Cylinder Material Vise Open/Close
Blade Down Feed Speed Dial Control Knob
Optional Micro Powerpack Gear Pump
Manual Blade Tensioning
Four Additional New Blades
2 HP Main Motor 220/60/3
1/4 HP Coolant Pump Motor
Overall Dimensions 80" W x 80-1/2" L x 55-1/2" High
Weight 1,800 Lbs.
