Hymmen ProfiCoater PFC S 1400

UV coating system
Used machine
Fully inspected

Economical
- Turbo system: 25% higher system performance thanks to state-of-the-art application technology, yet with the same space requirements!
- Shortened cycle times thanks to optimized automatic programming for fast UV systems
- Up to 70% cost savings compared to pouring and spraying thanks to the use of solvent-free systems and one-person operation

Flexible
- Thanks to cost-effective one-person operation with a return function or optionally in a continuous flow process for two-person operation
- The PC grows; Additional rolling, smoothing, or grinding units can be added.

Ergonomic
- Easy operation thanks to ergonomic controls

Service-friendly
- Thanks to cleaning circuit and quick-change system

Process-reliable
- Top-quality surfaces, precisely reproducible

Included:

- Roller conveyor, 2000 mm long
- ELX 1400 roller conveyor
- Bar conveyor, 3000 mm long
- UV drying channel with 1 lamp, 60/80/120 W

Technical specifications:
A B
PFC 1400 1300 mm 3080 mm

Working height: 850 - 950 mm
Rubber-coated application roller: D = 238 mm
Chrome-plated metering roller: D = 174 mm
Passage height: 3-120 mm
UV radiation module: 80/120 watts mercury
Power consumption: approx. 21 kW
