ICM 20, Index Cutting Machine

Cutting lenght ... max. 320 mm
Book thickness ... max. 70 mm
Cutting thickness … max. 5 mm at one cutting cycle, subject to paper type
Dimensions ... 1900 mm x 1300 mm x 1320 mm
Weight ... 900 kg
Electric supply … 3 Phase 400 V, 50 Hz, 6 kW

Machine requires compressed air supply (7 bars, clean dry air with no oil and dust)
Manufactured to CE electrical and safety standards.

The ICM series is the line of semi-automated index cutting machines. The purpose of the machine is to cut indexes into a finished books (soft cover and hard cover). Each book is inserted into the ICM machine, then the cutting process is automated according to cutting program, while operator controlling the index pages positions.

The cutting programs can be created by the means of a color touchscreen and can be saved into a memory as jobs. Operator screen offers language selection.

ICM machines feature the book clamping table with movement in 2 axis (horizontal left-right index position and vertical to follow the thickness of each cutting cycle). The cutting knives are replaceable and adjustable, allowing for several cutting patterns.

The latest model ICM 20 is fully servomotor driven and offers faster working cycle by efficient synchronisation of movements in the machine due to possibilities of servomotoric control.

ICM machines are equipped with Interface for remote diagnostics with a possibility to collect the processing data for management purposes, this can be developed and optimised on customers demand.
