Jagenberg Diana 145-4

General Machine Configuration:
Model: Jagenberg Diana 145-4
Type: Folder gluer
Format class: Large format, 145 cm class
Application: Suitable for corrugated box production, especially for large-size and heavy-duty boxes

Main Units Identified from the Photos
1. Feeder Section
Automatic feeder unit
Suitable for large-format corrugated board feeding
Adjustable side guides

2. Folding and Transfer Section
Extended and wide transfer section
Multi-belt transport system
Stable sheet transport for large box formats

3. Gluing System
Cold glue (PVA) infrastructure available
Valkomelt gluing system
3/4-point gluing capability
Multiple glue gun connection infrastructure

4. 4-Point Folding Unit
Suitable for crash-lock bottom / 4-point carton production
Important feature for value-added box styles

5. Press Section
Long press section
Provides stable pressure after gluing
Suitable for large and thick corrugated board

6. Delivery Section
Conveyor-type delivery
Suitable for smooth transfer and bundle preparation

Additional Equipment Confirmed:
Jagenberg breaker / separator
Mosca RO MP2 bundler
Linear rail-based manual adjustment elements
Top control / operator panel
Safety equipment such as guards and emergency stop buttons

Electrical Information Visible on the Nameplate:
Voltage: 3AC 400/230 V
Frequency: 50/60 Hz
Control voltage: 24 V DC
Nominal machine current: 78 A
Fuse rating: 80 A

Practical Production Capability:
Suitable for the corrugated industry
Can handle different flute types
Can also produce double-wall box styles such as BC and EB flute combinations, as well as other flute types
