JSW J100ADS-180U 45 100T

Ref : 2730642-6-CP
Condition : Used
Manufacturer : JSW
Model : J100ADS-180U 45
Capacity : 100T
Year(s) : 2023
Quantity : 1
Location : Seller or machines location:
EUROPE (Central and Eastern)

Total number of shots: 6800
Hours on: 60 h
Plate dimensions: 630 x 630 mm
Closing force: 1000 kN
Screw diameter: 45 mm
Injection capacity: 223 cm³
Injection weight: 203 g
Maximum distance between the plates for mounting the mold: 910 mm
Distance between the columns (horizontal): 460 mm
Distance between the columns (vertical): 460 mm
Maximum injection pressure: 157 MPa
Opening the mold: 360 mm
Max. Speed: 400 mm
Machine length: 4950 mm
Machine width: 1230 mm
Machine height: 1670 mm
Weight of the injection molding machine: 4600 kg
Equipment:
Manuals
Spare parts
1x SHINI SAL-3U-CE aspirator
1x SHINI vacuum aspirator
Molecular dryer SSD120U-80H
SHINI STM-607-W-CE Temperature Control Device
SHINI SIC-7.5A-R2 Cooling Device
Dual dosing of SHINI SCM dye
