Kama PROFOLD 74
EUROPE (Western and Northern)
Die Cutter (Hand Fed)
Max. size: 740x740 mm
Die-cut area: 100x120 mm
Mech. speed: 150 m/min
Power pressure: 36,000 cycles/h
Machine length: 5500x1000 mm
SHEET feeder:
A vacuum pump
Two individually controllable suction zones
A double-sheet detection sensor
Rotating pile break-up facility
A pile height of up to 300 mm (depending on the material)
TRANSPORT module and tool mounting grid
Length of the transport module: 2,750 mm
Eight-channel Omron programmable logic controller (PLC)
Interface to the hot-melt gluing system (Baumer-HHS)
Colour touch screen
Pressure rollers: 2 x with single roller, 2 x with three rollers, 4 x with six rollers, 2 x with 10 rollers.
Standard TOOLS:
1 x tipper fold plate
1 x left and 1 x right small plough fold device
1 x left and 1 x right large plough fold device
2 x controlled blowing air nozzles
Delivery unit
