Kao Ming KMC 4000 SV-H 4400 rpm Distance table to spindle nose: 213 - 1093 mm
Ref :
2778323-3-GO
Condition :
Used
Manufacturer :
Kao Ming
Model :
KMC 4000 SV-H
Spindle Speed :
4400 rpm
Spindle Size :
Distance table to spindle nose: 213 - 1093 mm
Year(s) :
2008
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
X travel: 4230 mm
Y travel: 2000 mm
Z travel: 750 mm
Feed rate X-axis: 12000 mm/min
Feed rate Y-axis: 15000 mm/min
Feed rate Z-axis: 12000 mm/min
Indexing horizontal head: 5° x 72 positions
Control: HeidenHain iTNC530
HR410 handwheel
Double guideway two box way construction
Head changer for multi-face machining
ATC tool changer
Swivelable horizontal and vertical milling head
Spindle torque: 1018 Nm
Spindle taper: ISO 50
Spindle speed: 4400 rpm
Spindle motor power: 26 kW
ATC: 30 positions
Distance between columns: 2100 mm
Table length: 4000 mm
Table width: 1600 mm
Table load: 11000 kg
Chip conveyor
Coolant system
Machine length: 10100 mm
Machine width: 4500 mm
Machine height: 4250 mm
Machine weight: 30000 kg
