Kitamura MYCENTER-4XD 3 Axis

X-axis travel: 1100 mm
Y-axis travel: 610 mm
Z-axis travel: 610 mm
Rapid feedrate X-axis: 36 m/min
Rapid feedrate Y-axis: 36 m/min
Rapid feedrate Z-axis: 30 m/min
Maximum cutting feedrate: 24000 mm/min
Control: FANUC 0i-MD
Coolant system
Interlocked guards
Swarf conveyor
Table size: 1270 x 640 mm
T-slots: 5 x 18 mm
Minimum height under spindle: 100 mm
Maximum height under spindle: 710 mm
Spindle speed: 10000 rpm
Tool holder taper: BT50
Tool change capacity: 30 stations
Tool change time: 5 s
Maximum tool diameter: 74 mm
Maximum tool diameter with adjacent pockets empty: 150 mm
Maximum tool length: 300 mm
Maximum tool weight: 8 kg
Maximum workpiece weight: 1200 kg
Machine weight: 7300 kg
