Komori GL840-P-CX HUV 28x40"

Eight-color 28x40" Offset Press
Ca 50 Mil Impressions

Equipped with:
8/0 to 4/4 Perfecting
AAPC Simultaneous Plate Change -change of all plates in approximately 80 seconds
AMR MakeReady Presets
PQC-S - Remote control console
PQA-S – Sheet inspection system
KHS-AI - Intelligent system with self-learning function for de-inking and pre-inking activities.
PDC-SX Spectrophotometric Quality Control (integrated type)
KID - Komori information display system.
KMS V Monitoring System
Automatic Blanket washer with 4 different washing programs
Automatic Impression cylinder washer with 4 different washing programs
Automatic Roller washing with 4 different washing programs
Automatic coating unit washing system
Ink mist extraction system for each printing unit.
Set for printing on plastic or metallic substrates
Cam adjustment with motorized gripper opening, programmable and with speed compensation
Start/stop dampening controls
Start/stop inking controls
Ink and dampening roller engagement/disengagement control for fast de-inking
Dampening liquid level sensor
Mechanical compensator for roller contact - Ensures consistent contact between rollers.
Inker temperature control
Remote ink distribution control between front and back rollers
Motorized ink fountain roller
Remote control of take-up roller timing
Anti-ghosting rollers for B and C with manual on/off system
Chameleon ink rollers
Inline Coater System Type V with 2000 mm extension
Shadowless grippers
1 Anilox chamber system with 1 anilox roller
1 Varnish circulation unit
Blanket clamp opening/closing for each coater without tools
Automatic pile side control
Pneumatic squaring
Double sensing foot with ionizing antistatic blower
Preset of side blowers
Antistatic bar
Feeder table with suction belt
Mechanical double-sheet control
Ultrasonic double-sheet control
Micrometric adjustment of the side squaring via touch panel +/- 3 mm
End of press: 1 lamp (H-UV lamp and a conventional UV lamp)
Drying unit: 1 lamp (H-UV lamp and a conventional UV lamp)
Interdeck: 3 interdeck lamps moveable between 5 positions (H-UV lamp and a conventional UV lamp)
