Komori Lithrone S-540 H C 102 x 72 cm

Colors: 5
Size: 102 x 72 cm
Approx 87 mio impressions
Control and Monitoring Systems
• Remote Quality Control System PQC-S (Print Quality Control System):
* Remote ink control
* Remote dampening control
* Remote register control:
o Longitudinal ( /- 2 mm)
o Lateral ( /- 3 mm)

Cylinder Control Parameters:
• Diagonal – plate ( /- 0.2 mm)
• Remote cylinder skew control – at feeder ( /- 0.3 mm)
• Remote cylinder stretch control – at feeder (0 – 0.6 mm)
• Komori Management System – KMS 4
• 2x touchscreen control monitors
• Advanced printing control system – Komori KHS

o X-Rite IntelliTrax:
* Automatic spectrodensitometer
* Online spectrophotometric sheet control
* Printflow Color Control Software
Production Process Automation
• Automatic impression cylinder washing
• Automatic inking unit washing
• Automatic blanket cylinder washing
• Preset for substrate thickness adjustment
• Automatic Format Preset:
* Feeder head
* Side lay
* Brushes and rollers on delivery table
* Side air blower
* Jogging and braking
* Remote head and impression settings

Feeder:
• Stream feeder with 1150 mm pile height
• Feeder head with lifting and forwarding suckers (2x)
• Deionizing blower
• Carton equipment
• Suction belt feed table
• Electronic side lay and front lay control
• Front lay bar skew adjustment
• Ultrasonic double-sheet detector
• Non-stop feeding function
• Electronic pile height control
• Pneumatic side lay

Inking Unit
• Precise ink feed adjustment (500 ink key opening steps)
• Inking unit with 20 rollers, including 4 form rollers of various diameters
• Adjustable ductor dwell timing
• Remote inking zone control from PQC-S console
• Separate vibrator drive
• Ink vibrator cooling system
• Remote axial roller movement adjustment
• Option to disengage drive of first and last unit

KOMORIMATIC Dampening Unit
• Continuous dampening – suitable for alcohol and alcohol-free printing
• Oscillating distributing roller prevents banding
• Reduced feed roller speed
• Pneumatic engagement/disengagement from console
• Dampening solution level sensor

Coating Unit
• Suitable for aqueous and UV coatings
• Remote register and substrate thickness adjustment
• Special shadowless grippers
• Extended delivery: 2.00 m
• Compatible with both rubber blankets and photopolymer plates
• Chambered doctor blade system TRESU

Delivery
• High pile delivery with 1150 mm stack height
• Sheet decurler
• Deionizing bar
• Automatic lubrication of delivery chains
• Production counter
• Mechanical pull-out of sample sheet
• Grafix Megatronic powder spray device:
* Automatic speed compensation
* Powder level monitoring
• Engagement/disengagement of dampening and inking rollers

Auxiliary Equipment:
• Plate punch: BEIL Registersysteme GMBH 830-S-H-Manual
• Plate bender

Cooling and Circulation Systems:
• Dampening solution cooling: Technotrans Alpha.d 60L-5 Combicontrol 2.5 aquados.a 5
• Ink vibrator circulation and cooling: Technotrans Alpha.t 120 L-5
• IR dryer: Baldwin IVT Graphiset4 (48 kW)
• Dispersion coating circulation: Technotrans Alpha vBandwith electric pumps

Additional Equipment:
• Anilox roller: APEX – 120 l/cm
• Feeder pump: DVT 3.140 – Becker
• Transformer: 150 kVA – SBA
• Filters: MIF 3340 EMC – Deltron Radikor
• PQC console lighting – Just
• 5 sets of inking and dampening rollers – Westland/Böttcher
• Spare dampening rollers for all units
• Spare inking roller cores

Optional Equipment:
• Data converter: CIP ¾
• Compressor set: EPC 630-250 – Gietart/Kaeser
