Krauss Maffei CX 300 300 ton

Tonnage: 300 ton
Shot Weight (Max): 981 g
Distance Between Tie-Bars (H): 630 mm
Distance Between Tie-Bars (V): 630 mm
Platen Size (H): 995 mm
Platen Size (V): 1050 mm
Screw Diameter: 70 mm
Tie-Bar Diameter: 145 mm
Mould Height (Max): 330 mm
Daylight Between Platens (Max): 1150 mm
Clamping Speed: 840 mm/s
Opening Stroke (Max): 820 mm
Ejector Force: 57 ton
Ejector Stroke: 200 mm
Number of Core Pulls: 1
Dry Cycle: 2.7 s
Injection Volume: 1078 cm³
Injection Pressure: 1877 bar
Injection Rate: 385 cm³/s
Nozzle Force (Max): 8 ton
Nozzle Stroke (Max): 600 mm
Heating Zones: 6
Heating Capacity: 29 kW
Oil Tank Capacity: 720 l

Equipped With
Core pull(s)
