Leica M822 F40 Surgical Microscope

Leica M822 F40 Surgical Microscope.
Used, refurbished Leica M822 ophthalmic surgical microscope on F40 floor stand.
The Leica M822 is a specialized ophthalmic microscope.
The microscope is fully functional and in very good technical and visual condition.

APPLICATION
Ophthalmology

MICROSCOPE HEAD
MAGNIFICATION
3x – 18,8x
Continuously magnification adjustment
Speed adjustment
Motorized zoom system

OBJECTIVE LENS
f=200 mm
Fixed focal length objective
Speed adjustment
Motorized

X-Y COUPLING
50 x 50 mm
Speed adjustment
Motorized

ASSISTANT ATTACHMENT
Stereo assistant attachment (Side view)

MAIN SURGEON
Binocular tube, tiltable 10° – 50°
10x Eyepieces
Adjustable interpupillary distance

ASSISTANT
Binocular tube, tiltable 5° – 25°
10x Eyepieces


Adjustable interpupillary distance

TILT MECHANISM
+ 15 /- 50°
Motorized

MICROSCOPE HEAD POSITIONING
High-precision electromagnetic brakes

LIGHT SOURCE
TYPE
Integrated in the microscope head (direct)
Integrated Red Reflex illumination

MAIN ILLUMINATION
LED 50W
2 x Halogen 50W

LIGHT INTENSITY ADJUSTMENT
Smooth, electric adjustment of the illumination intensity directly via the foot control and the control unit on the mobile stand

SUSPENSION SYSTEM
TYPE Floor stand
POSITIONING OF THE SUSPENSION SYSTEM High-precision electromagnetic brakes
BALANCING Manual
CONTROL UNIT LCD graphic display

The menu allows storing user-specific settings
FOOT CONTROL 16 function, Wireless

DIMENSIONS
Transport position: 115 x 61 x 191 cm
Mobile base: 61 x 61 cm

WEIGHT 330 kg

OPTIONAL EQUIPMENT
Video system
Monitor
Slit lamp
