Lemo INTERmat ST-N / CT Plastic Bag Making Machine

Working width: 600 / 850 / 1100 mm
Number of lanes: 1
Bag width / feed length: 420 / 640 / 860 mm options
Total bag height: 600 / 850 / 1100 mm
Mechanical cycle speed: 350–450 cycles/min
Web / film speed: 15–125 m/min
Electrical connection: 3 x 400 V / N / PE, 50/60 Hz
Total connected load: 20 kVA
Back-up fuse: 80 A
Compressed air: 6–8 bar
Compressed air consumption: approx. 2,800 Nl/min
Cooling water pressure: 4–6 bar
Cooling water temperature: 18–24 °C
Noise level: approx. 80–82 dB(A)

Main Equipment of the Machine:
FA-U film unwinder
Touch screen control panel
Main machine body
BF bottom gusseting unit
FD folding triangle
ZVZ additional feed roller pair
Pre-welding unit
Hole punch device
Two-hole punch device
TS sealing unit
ST-N product discharge / stacking unit
Pin stacker system
Pneumatic sealing system
Pneumatic rocker / crush roller system
Pneumatic stacker
Emergency stop points
Control panels and touch screen

Main Advantages:
The machine is designed for high-volume continuous production.
Suitable for different film types and film thicknesses.
Flexible adjustment according to the sealing behaviour of the film.
Individually adjustable sealing time, temperature and pressure.
High production performance.
Fast adjustment and easy operation.
Stable dimensional accuracy.
Low maintenance requirements.
Good product quality and high production reliability.
