MAN Lithoman II 4

Web Offset Book Press
Cut Off: 2 x 445 mm
Cylinder Circ: 890 mm (35”)
Non-Print Gap: 13mm
Max Web Width: 1270 mm
Min Web Width: 420mm
Max Mech Speed: 35,000 CPH
Running Direction: Left to Right.

Comprising of:
(2) MEG DLC Zero Speed Splicers
• Integrated Infeeds
• Auto reel loading

(1) Procemex-7X Web Monitoring System
(4) MAN Lithoman Printing Units
• OxyDry RO blanket wash
• Betz automatic ink levellers

(1) Web Path Rollers Over Print Units 3 & 4
(1) Technotrans Dampening Water Circulation
(2) Grafotec Web Severers
(2) 12M VITS OTII Hot Air Dryers
• No integrated afterburner

(2) MAN 6 Chill Roll Stands
(2) E&L Web Guides
(2) MEG Remoistening Systems
(2) WEKO Silicon Applicator

(1) MAN Folder Superstructure for 2 Webs
• Slitters
• Air loaded angle bars
• Driven ribbon pull rollers
• Web compensators
• 2 Air loaded formers

(1) MAN FLB32 Pinless Book Folder
• Two piece knife cylinder
• Five around collect cylinder
• Four around transfer cylinder
• Delivery for 1⁄4 fold
• Delivery for Cross Fold

(2) Planatol Opimatic Softjet Fold Softening Systems
(1) QuadTech CCS (Opti 1) Closed Loop Colour Register Control c.2009
(1) QuadTech Multicam Colour Register Control c.2009
(1) QuadTech RCS Ribbon Register Control c.2009
(1) Folder Control Sation
(1) Main Control Desk
(2) Colour Desks
(1) MAN Remote Ink Control System
(1) Electrical Drive System
(1) Plate Bender
(1) Sulzer Temperature Control Unit
(1) Set of Drawings and Manuals

Post Press
(1) Exit Conveyors
(1) Stream Alignment Jogger
(1) Moveable Gate to Select Folder Delivery
(1) Civiemme ST420 Log Stacker
(1) Civiemme PL86 Palletizer

PRODUCTION
This press is designed for the production of:
‘A5’ Long Grain: (148.5 x 210mm) (5.9” x 8.3”)
‘B Format’ Long Grain: (129 x 196mm) (5” x 7.8”)
‘A4’ Short Grain: (210 x 297mm) (8.3” x 11.7”)
