MAN Roland 904-8 XXL 1,300 × 1,850 mm

- Max. sheet size: 1,300 × 1,850 mm
- Maximum printing speed: 10,000 sheets/hour (depending on substrate and job type)
- Substrate thickness: 0.08 mm – 1.0 mm
- Remote control from the central control desk
- Two double-sheet detectors
- Stream-fed sheet delivery to the feeder unit by feed table with suction tapes
- Patented steel feed table with suction tape conveyor
- Anti Static device
- Feeder cylinder
- Interchangeable gripper tips
- Printing units : 7 o'clock arrangement of cylinders
- Double-diameter impression cylinders
- Contact-free sheet transfer
- Quick-clamp system for blankets
- GRAPHO-METRONIC plate punching system
- Refined (hardened/treated) surfaces of impression, transfer and plate cylinders
- PPL- semi-automatic plate changing system
- Brush washer for blanket cylinders
- Axial oscillation inking units
- RCI controlled oscillating zones
- Remotely controlled ink roller washing system
- ROLAND-DEL TAMATIC dampening units
- Ink temperature control
- Temperature-controlled dampening solution tank
- All inking and dampening units can be cleaned simultaneously
- High pile delivery
- Air-Glide delivery pile system
- Sheet guiding belt with controlled airflow
- Suction roller with speed compensation
- Grafix Cantronic powder spraying device
- Grouping of lubrication points for individual units
- Central oil change for the entire machine
- Air supply
- Control Panel-Equipment
- Colour monitor
- Membrane keyboard
- Lamp for colour checking
- Computer with hard drive for storing production data
- Inkjet printer for reports
- Control Panel Functions
- CE certified machine
- Kersten deionizer
- Additional double-sheet control (detects 2 sheets at once)
- Brush washer for impression cylinders of printing units
- Air supply system consisting of a pressure tank and cooler
- Powder extraction system by Grafix
- IR drying system Roland Seccomatic
- Comfort Plus package (control panel)
- Additional drawers
- Light protection shield
- Adjustable console tilt (BEIL)
- Pressnet
- Telepresence
- Printer's tool box (PODE)
- Prepresslink
- Job Pilot/ Press Monitor
