Mayer 6062

Used 10ft beam saw
• Cutting length 125.9" (3,200 mm), 4.1" (105 mm) max saw blade projection,
12 HP (9 kW) main saw motor & 1.5 HP (1.1 kW) scoring motor, 355 mm dia. main blade and 127 mm dia. score blade dia.
• Saw carriage with rack & pinion drive;
• Electronically controlled overhead program fence with rack & pinion drive on hardened & ground guideways,
• Equipped with: (6) Clamps (open up to 3.1" / 80 mm);
AC Servo motor drives on both the saw carriage and pusher fence; rear table with double row support rollers.
• PC front end with "IPC 5000"
• Machine equipped with Rear support rails with rollers;
78.7" long cross-cut fence; automatic side aligner (3) front mounted air table (78" x 25");
