Mazak HCN 6000 4 Axis

MAZAK HCN 6000
2005

Pallet size 19.68 in x 19.68 in
Number of pallets 2
Pallet weight capacity 2204 lb
Pallet surface to spindle center 5.91 in to 37.4 in
Pallet center to spindle gauge line 3.94 in to 35.43 in
Workpiece dimensions 35.4 in x 39.37 in
X-axis travel 31.5 in
Y-axis travel 31.5 in
Z-axis travel 32.5 in
B-axis travel 1 degree
Rapid traverse X 2362 in/min
Rapid traverse Y 2362 in/min
Rapid traverse Z 2362 in/min
Cutting feed rate 2362 in/sec
Spindle speed 10000 rpm
Spindle taper CT#50
Spindle motor 50 hp
Automatic tool changer 43 tools
Tool diameter 4.92 in / 10.24 in
Tool length 19.69 in
Tool weight 66 lb
Machine weight 32408 lb
Control MAZATROL FUSION 640M
Coolant through spindle
Chip conveyor
Probe
EIA programming
Spiral interpolation
3D EIA compensation
Geometric compensation
Scaling
External data I/O
Shape compensation
Thread cutting
Inverse time programming
Automatic tool length measurement
G54.1 offset
Synchronous tapping
Inch/millimeter conversion
G00 slope constant
600 variable sets
Navigation functions
EIA helical tapping
MAZATROL helical interpolation
Coordinate shift
Planetary tapping
