Mazak Mazatrol PC Fusion CNC 640MT Pro 3300 rpm INTEGREX 400-3S 5 Axis

X-axis travel: 630 mm
Y-axis travel: ±115 mm
Z-axis travel: 1585 mm
Rapid traverse X-axis: 38 m/min
Rapid traverse Z-axis: 38 m/min
Rapid traverse Y-axis: 26 m/min
C-axis resolution main spindle: 0.001°
B-axis swiveling range: -30° to +195°
Control: Mazatrol PC Fusion CNC 640MT Pro
Coolant capacity: 444 l
Coolant through milling spindle: 15 bar
Maximum bar diameter: 102 / 77 mm
Swing diameter: 760 mm
Maximum turning diameter: 760 mm
Distance between centers: 1500 mm
Maximum turning length: 1524 mm
Main spindle nose: A2-8
Main spindle bore: 112 mm
Main spindle speed range: 35–3300 rpm
Main spindle power: 30 kW
Main spindle max torque: 1200 Nm
Back spindle nose: A2-8
Back spindle bore: 88 mm
Back spindle speed range: 35–4000 rpm
Back spindle power: 26 / 22 kW
Back spindle max torque: 500 Nm
Milling spindle interface: CAPTO C6
Milling spindle speed range: 15–12000 rpm
Milling spindle power: 18.5 kW
Milling spindle torque: 120 Nm
Feedrate range: 0–8000 mm/min
Tool magazine capacity: 40 stations
Maximum tool diameter: 90 mm
Maximum tool diameter with free adjacent pockets: 125 mm
Maximum tool length: 400 mm
Machine weight: approx. 13,300 kg
Required floor space: 5110 x 2196 mm
Machine height: 2798 mm

Features / options / equipment
Linear scale system on X-axis
3-jaw chuck Ø400 mm
3-jaw chuck Ø315 mm (back spindle)
Hydraulic chuck
Spindle synchronization
Spindle blow-out (back spindle)
Air blast through milling spindle
RS232 interface
PCMCIA interface
Synchronized tapping
Chip conveyor
Foot pedal
Machine lamp
